| Payment Type: | L/C,T/T |
|---|---|
| Incoterm: | FOB,CFR,CIF,EXW |
| Min. Order: | 1 Set/Sets |
Basic Info
Model No.: EX8050
Brand: Wenpeng
Applicable Industry: Building Material Shops, Farms, Construction Works, Energy &Amp; Mining, Other
Out-of-warranty Service: Video Technical Support, Online Support
Place Of Origin: China
Status: New
Exercise: Crawler Excavator
Warranty Period: 1 Year
Engine Brand: Cummins
Mechanical Test Report: Provided
Video Factory Inspection: Provided
Operating Mass: 77.2T
Bucket Capacity: 3.5-5m³
Additional Info
Productivity: 100sets/month
Transportation: Ocean,Land
Place of Origin: China
Supply Ability: 100sets/month
Certificate: CE
Port: Qingdao
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
Product Description
| Model | EX8050 |
| Engine model | Cummins QSX15 |
| Working mass | 77.2T |
| Bucket capacity | 3.5-5m³ |
| Power | 336/14800kw/r/min |
| Volume of fuel tank | 950L |
| Travel speed (High/Low) | 4.8/3 km/h |
| Swing speed | 7.2 r/min |
| Gradeability | 35 |
| Digging force of bucket | 300/328KN |
| Digging force of stick | 238/260KN |
| Specific pressure of ground contact | 100Kpa |
| Traction | 553KN |
| Maximum flow | 490*2 L/min |
| Working pressure | 34.3/37Mpa |
| Volume of hydraulic fluid tank | 335L |
| A-Overall length | 13104mm |
| B-Overall Width | 4256mm |
| C-Overall height(tope of boom) | 5269mm |
| D-Overall height(tope of cab) | 3530mm |
| E-Gap from counterweight to ground | 1600mm |
| F-Min ground clearance | 898mm |
| G-Tail swing radius | 4500mm |
| H-Length of track on ground | 4720mm |
| J-Track length | 5957mm |
| K-Gauge | 2750/3350mm |
| L-Width of track | 3400/4000mm |
| M-Width of track shoe | 650mm |
| N-Width of turning table | 3995mm |
| O-Max. digging height | 11673mm |
| P-Max. dumping height | 7642mm |
| Q-Max. digging depth | 6868mm |
| T-Max. digging distance | 11762mm |
| U-Max. digging distance at plane | 12064mm |
| V-Min. swing radius | 5070mm |
| W-Max height at min swing radius | 9890mm |
| X-Distance from center of swing to rear end | 4500mm |
| Y-Thickness of track grouses | 50mm |
| Z-Height of counterweight | 2900mm |
| Ground Contact length (in transportation) | 7394mm |
| Length of stick | 3020mm |
| Length of boom | 7100mm |
