| Payment Type: | L/C,T/T |
|---|---|
| Incoterm: | FOB,CFR,CIF,EXW |
| Min. Order: | 1 Set/Sets |
Basic Info
Model No.: EX1350
Brand: Wenpeng
Applicable Industry: Building Material Shops, Farms, Construction Works, Energy &Amp; Mining, Other
Out-of-warranty Service: Video Technical Support, Online Support
Place Of Origin: China
Status: New
Exercise: Crawler Excavator
Warranty Period: 1 Year
Engine Brand: Cummins
Mechanical Test Report: Provided
Video Factory Inspection: Provided
Operating Mass: 125ton
Bucket Capacity: 7.6-10m³
Additional Info
Productivity: 100sets/month
Transportation: Ocean,Land
Place of Origin: China
Supply Ability: 100sets/month
Certificate: CE
Port: Qingdao
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
Product Description
| Model | EX1350 |
| Engine model | Cummins QSK23 |
| Working mass | 125T |
| Bucket capacity | 7.6-10m³ |
| Power | 567/1800kw/r/min |
| Volume of fuel tank | 1600L |
| Travel speed (High/Low) | 3.2/2.2 km/h |
| Swing speed | 7.6 r/min |
| Gradeability | 35 |
| Digging force of bucket | 619KN |
| Digging force of stick | 467KN |
| Specific pressure of ground contact | 150Kpa |
| Traction | 756KN |
| Maximum flow | 550*3 L/min |
| Working pressure | 34.3/37Mpa |
| Volume of hydraulic fluid tank | 1070L |
| A-Overall length | 14882mm |
| B-Overall Width | 5665mm |
| C-Overall height(tope of boom) | 6350mm |
| D-Overall height(tope of cab) | 4236mm |
| E-Gap from counterweight to ground | 1904mm |
| F-Min ground clearance | 1070mm |
| G-Tail swing radius | 4987mm |
| H-Length of track on ground | 5109mm |
| J-Track length | 6500mm |
| K-Gauge | 3900mm |
| L-Width of track | 4600mm |
| M-Width of track shoe | 700mm |
| N-Width of turning table | 3534mm |
| O-Max. digging height | 12525mm |
| P-Max. dumping height | 7990mm |
| Q-Max. digging depth | 8110mm |
| T-Max. digging distance | 13870mm |
| U-Max. digging distance at plane | 13470mm |
| V-Min. swing radius | 6772mm |
| W-Max height at min swing radius | 10675mm |
| X-Distance from center of swing to rear end | 4987mm |
| Y-Thickness of track grouses | 52mm |
| Z-Height of counterweight | 3818mm |
| Ground Contact length (in transportation) | 8520mm |
| Length of stick | 3400mm |
| Length of boom | 7550mm |
Product Categories : Constrction Machine And Truck > Excavator
