| Payment Type: | L/C,T/T |
|---|---|
| Incoterm: | FOB,CFR,CIF,EXW |
| Min. Order: | 1 Set/Sets |
Basic Info
Model No.: EX360
Brand: Wenpeng
Applicable Industry: Building Material Shops, Machinery Repair Shops, Farms, Construction Works, Energy &Amp; Mining, Other
Out-of-warranty Service: Video Technical Support, Online Support
Place Of Origin: China
Status: New
Exercise: Crawler Excavator
Warranty Period: 1 Year
Engine Brand: Cummins
Mechanical Test Report: Provided
Video Factory Inspection: Provided
Operating Mass: 36ton
Bucket Capacity: 1.6-1.8m³
Additional Info
Productivity: 100sets/month
Transportation: Ocean
Place of Origin: China
Supply Ability: 100sets/month
Certificate: CE
Port: Qingdao
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
Product Description
Wenpeng Machinery Factory supplies a 36-ton large mining crawler excavator equipped with a 1.6 m³ bucket, which boasts excellent excavation capacity and efficient operational performance, making it an ideal choice for mining and earthwork engineering. The product quality meets CE and Euro 5 standards, and your inquiry is welcome!
| Model | EX360 |
|---|---|
| Engine Model | Cummins QSC8.9 |
| Working Mass | 36T |
| Bucket Capacity | 1.6-1.8 m³ |
| Power | 242/2000 kW/r/min |
| Fuel Tank Volume | 650L |
| Travel Speed (High/Low) | 6.2/4 km/h |
| Swing Speed | 8.2 r/min |
| Gradeability | 35° |
| Digging Force of Bucket | 245 kN |
| Digging Force of Stick | 185 kN |
| Specific Pressure of Ground Contact | 70.8 KPa |
| Traction | 247.8 kN |
| Maximum Flow | 270*2 + 30 L/min |
| Working Pressure | 37 Mpa |
| Hydraulic Fluid Tank Volume | 310L |
| A-Overall Length | 11187 mm |
| B-Overall Width | 3190 mm |
| C-Overall Height (Top of Boom) | 3180 mm |
| D-Overall Height (Top of Cab) | 3165 mm |
| E-Gap from Counterweight to Ground | 1190 mm |
| F-Minimum Ground Clearance | 498 mm |
| G-Tail Swing Radius | 3525 mm |
| H-Length of Track on Ground | 4030 mm |
| J-Track Length | 4945 mm |
| K-Gauge | 2590 mm |
| L-Width of Track | 3190 mm |
| M-Width of Track Shoe | 600 mm |
| N-Width of Turning Table | 2995 mm |
| O-Max. Digging Height | 10200 mm |
| P-Max. Dumping Height | 7135 mm |
| Q-Max. Digging Depth | 7370 mm |
| T-Max. Digging Distance | 11100 mm |
| U-Max. Digging Distance at Plane | 10910 mm |
| V-Min. Swing Radius | 4265 mm |
| W-Max Height at Min Swing Radius | 8500 mm |
| X-Distance from Center of Swing to Rear End | 3525 mm |
| Y-Thickness of Track Grousers | 30 mm |
| Z-Height of Counterweight | 2627 mm |
| Ground Contact Length (in Transportation) | 5875 mm |
| Length of Stick | 3185 mm |
| Length of Boom | 6470 mm |
