| Unit Price: | USD 53500 / Piece/Pieces |
|---|---|
| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CFR,CIF,EXW |
| Min. Order: | 1 Piece/Pieces |
Basic Info
Model No.: WP-1165A
Brand: Wenopeng
Additional Info
Packaging: exported packing
Productivity: 500 pcs/ month
Transportation: Ocean,Land
Place of Origin: China
Supply Ability: 500 pcs/ month
Certificate: CE/ISO
HS Code: 8479109000
Port: Q,i,n
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
Product Description
The company's main products include excavators, loaders, bulldozers, single-wheel rollers, double-wheel rollers, Bulldozer attachments, vibratory rollers, and road roller trucks. The product range is comprehensive, catering to users of all ages and diverse needs. The company boasts a professional R&D team and continuously introduces new products to meet market demands.
The Wenpeng mechanical grader employs advanced hydraulic systems and electronic control technologies, enabling precise leveling operations. Its key components include an engine, drive system, hydraulic system, control system, and working devices. The engine uses imported brands, offering high power, low noise, and minimal fuel consumption. The drive system utilizes hydraulic transmission for smooth and precise control. The hydraulic system features imported brands, ensuring stable and reliable performance. The control system incorporates electronic controls, making it user-friendly and capable of automatic operation. The working devices, such as the disc cutter, flat plate, and front and rear wheels, facilitate efficient leveling operations.
The Wenpeng mechanical grader is versatile and suitable for various terrains and engineering projects, capable of performing leveling operations at different depths and widths. Its advantages include high flatness, efficiency, ease of operation, and low maintenance costs. Consequently, the Wenpeng mechanical grader is widely used in construction, road, bridge, airport, and dock projects.
| Parameter | Value |
|---|---|
| Maximum depth of cutting | 500mm |
| Maximum lift above ground | 460mm |
| Maximum blade position angle | 90° |
| Circle reversing rotation | 360° |
| Moldboard width x height | 3665 x 610mm |
| Drive tires | 4 |
| Max. steering angle of front wheels | ±45° |
| Max. lean angle of front wheels | ±12° |
| Max. oscillation angle of tracks | ±15° |
| Frame articulation angle | ±23° |
| Minimum turning radius | 7.7m |
| Travelling speed (forward) | 5, 8, 11.19, 23, 38 km/h |
| Travelling speed (reverse) | 5, 11, 23 km/h |
| Maximum traction | 79 kN |
| Max gradeability | N/A |
| Engine model | 6BTA5.9-C170 |
| Rated power/speed | 125/2200 kW/rpm |
| Maximum torque/speed | 750/1300 N.m/rpm |
| Dimension (LxWxH) | 9050 x 2620 x 3500 mm |
| Dimension (LxWxH) with Hoshon Pottery | 9670 x 2620 x 3500 mm |
| Operating weight | 14800 kg |
Product Categories : Constrction Machine And Truck > Compactor And Scree
